 > 제품소개 > 무급유식 스크류 컴프레서 - HP Series |
|
 |
| |
| |
 |
| MODEL |
HP-1.5PA |
HP-2.2PA |
HP-3.7PA |
HP-5.5PA |
HP-7.5PA |
HP-11PA |
Comp
ressor |
Max. Pressure |
kg/ ㎠ |
9.5 |
8.5 |
Control Pressure
(On-Off) |
kg/ ㎠ |
8~9.5 |
7~8.5 |
| Compressed Air Volume |
ℓ/min |
170 |
250 |
420 |
625 |
830 |
1,225 |
Cylinder Dia. (mm)×
Dimension(mm)× No. of
Cylinder |
|
82×60×1 |
82×60×2 |
82×72×2 |
82×72×3 |
105×72×2 |
105×72×3 |
| |
No. of Rotation |
rpm |
880 |
650 |
850 |
860 |
1,050 |
1,030 |
| Motor |
Output |
kW |
1.5 |
2.2 |
3.7 |
5.5 |
7.5 |
11 |
| Power |
|
3PH, 220V / 380V / 440V, 60Hz |
| Compressed Air Outlet |
inch |
3/8(10A) |
1/2(15A) |
| Air Tank Capacity |
ℓ |
28 |
32 |
| Noise (Front 1.5m) |
dB(A) |
55 |
55 |
57 |
60 |
64 |
68 |
| Dimension(L×W×H) |
mm |
804×680×1,040 |
884×720×1,040 |
845×870×1,215 |
1,050×940×1,400 |
| Weight |
kg |
110 |
123 |
168 |
300 |
320 |
460 |
|
|
|
|
|
|
